Name: Utility Vehicle Atv 500cc Atv 25L Big Oil Tank EFI Starting Model
Brand: Shanghai Rongyao Vehicle Co.,Ltd
SKU: veículo utilitário atv50009
Availability: InStock

Para casa > produtos > Veículos utilitários ATV >

Utility Vehicle Atv 500cc Atv 25L Big Oil Tank EFI Starting Model

Lugar de origem:

China

Marca:

RONGYAO

Certificação:

EC,EEC,DOT,EPA

Número do modelo:

veículo utilitário atv50009

Contacte-nos

Solicite um orçamento

Utility Vehicle Atv 500cc Atv 25L Big Oil Tank EFI Starting Model

Detalhes do produto

Nome do produto:

quadriciclo para veículo utilitário 500cc

Transmissão:

CVT

Dimensão de produção:

2386×1125×1217mm

Suspensão, parte dianteira/parte traseira:

Suspensão independente com balancim duplo

Tipo de inicialização:

Partida elétrica

Taxa de compressão:

10.3:1

Termos de pagamento e envio

Quantidade de ordem mínima

Preço

negotiable

Detalhes da embalagem

Quadro do metal com caixa

Tempo de entrega

Dentro de 20 dias

Termos de pagamento

T/T, União Ocidental,

Habilidade da fonte

1000 unidades/mês

PRODUTOS CONEXOS

Atacado 500cc ATV de corrida para adultos 4*2 Transmissão automática refrigerada a água Tração nas quatro rodas Peças e acessórios UTV off-road grandes

Obtenha o melhor preço

Bashan 300cc 4WD Quad Bike ATV com freio de disco hidráulico

Obtenha o melhor preço

Mud ATV 600cc 650cc 2 assentos off-road 4 Wheel Quatro Wheeler Buggy

Obtenha o melhor preço

Alta Qualidade 400cc 4X4 Quad Bike Road Legal ATV Automático Drive de eixo Equipado Com Diferencial Bloqueio Elétrico Atvs Starter com preço no atacado

Obtenha o melhor preço

Contacte-nos

0086-13761175834

sales@fourwheel-atv.com

Contacte agora

Descrição do produto

Utility Vehicle Atv 500cc Atv 25L Big Oil Tank EFI Starting Model

Model:

utility vehicle atv50009

Product Description:

Dimensions: L× W × H:2386×1125×1217mm
Packaging size:2300*1200*1200mm
Wheelbase:1460mm
Ground clearance:262mm
Fuel tank capacity:25L
N.W // G.W:About 365kg //About 456kg
Tyre:Front:24×8.00-12 Rear:24x10.00-10
Braking:Disc Brake
Suspension:Front/Rear: Double rocker arm independent suspension
Shock absorption:Front/back: Helical spring + oil damping type
Engine type:Single-cylinder,water-cooled,four-stroke,500cc
Startup mode:EFI
Startup type:Electric start
Bore × stroke:91×76.5mm
Maximum power/Corresponding rotational speed:34kw/6750rpm
Maximum torque/corresponding rotational speed:39N.m/5759rpm
Compressionration:10.3:1
Optional Colors:Black,White

Applications:

1. adult

2. Forest road

3. Riverbed, Stream

4. Mountain Road

5. Beach

6. Farm

7. Pleasure Ground

Terms of transaction:

Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or . The delivery time is about 20 days.

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Company Information;

1. All of the ATV Frame is use the 2.5mm seamless steel pipe ligt arc welding,production by our factory workeshop.reliable and stability.

2. All of the ATV engine is come from original engine factory. have not the renovation engine.

3.Each one ATV come out from factory, All must go through rigorous drive testing.To ensure the quality of each ATV.

4.We have one Professional team to do the after-sales service, Provide the solution to solve your worries on the ATV problems.

Warranty time
We supply you 12 months for warranty time, during the warranty time, we supply you free parts!!
